SDM (Sensing and Diagnostic Module)

What the SDM does on your Cadillac

As GM's luxury division, Cadillac shares the corporate airbag computer, the SDM, or Sensing and Diagnostic Module. On an Escalade, a CTS or an XT5, the SDM runs the supplemental restraint system, fires the airbags and pretensioners in a crash, and writes a permanent deployment record to its memory.

That record locks the module, which is why the SRS light will not go out on its own and a scanner cannot clear it. We reset your original Cadillac SDM in our shop, erase the stored crash data and hard codes, and return it factory-ready. Dealers often quote a new module plus programming for Cadillacs. Resetting your own part costs a fraction of that.

Where it lives

Where the Cadillac SDM is located

On most Cadillacs the SDM lives under the center console between the front seats, mounted to the floor pan, the same architecture as the rest of GM. On the Escalade, which shares the full-size truck platform, it can sit under the console or beneath a front seat. You remove the console trim to reach it.

Disconnect the battery and let the system discharge before you touch the restraint wiring. Then unbolt the module from its bracket and unplug the connector. The exact location moves a little between the Escalade, CTS, ATS, XT5 and SRX. If yours is hard to find, call us and we will guide you to it.

Common Cadillac SRS codes

Cadillac airbag codes we clear every day

Cadillac uses GM's B-series SRS codes. Deployment and crash-data codes clear with a reset. Some flag a circuit or a part. Scan it and look yours up first.

B0001Driver deployment commanded B0012Driver stage 2 loop B1000ECU internal fault B0051Restraint deployment B0081Passenger presence sensor B1327Battery voltage low

Every Cadillac airbag code, explained

Look up your code

Cadillac models we service

Cadillac models we work on every week

Every Cadillac from 1996 and newer, we handle the SDM and the seat belts. These are the ones we see most.

Escalade and Escalade ESV
CTS and CT5
ATS
XT5
SRX
XTS
DeVille and DTS
XT4 and XT6

Est. 1997 · Glaze family

What we do for your Cadillac

We reset your original Cadillac SDM and clear the stored crash data so the SRS light goes out. We also rebuild Cadillac single, dual, and triple-stage seat belt pretensioners and free locked retractors. Your factory parts come back restored to original operation.

Module reset Seat belt repair

Other makes

We service every make, 1996 and newer

We run the same restoration work across every make. Here are a few more we handle every week.

Chevrolet

Same GM SDM platform. Silverado, Tahoe, Equinox and more.

Chevrolet airbag service →

GMC

Shares the SDM and the truck platform. Sierra, Yukon, Acadia.

GMC airbag service →

Buick

GM's other near-luxury line on the SDM. Enclave, LaCrosse.

Buick airbag service →

Audi

German luxury, airbag control module. A4, Q5, A6 and more.

Audi airbag service →

See all makes

By model

Popular Cadillac models we restore

Pick your vehicle for its module location, common fault codes, and exactly what we restore. We handle every Cadillac from 1996 on, so call if you do not see yours.

Cadillac EscaladeModule reset & belt repair →

Restore your Cadillac

Get your Cadillac SRS light off

Mail us your original SDM or seat belt. We clear the crash data, rebuild the pretensioner, and ship your factory part back ready to install.

Shop genuine OEM parts Call 501-988-0611

Cadillac airbags, seat belts, and modules in stock

Shop all Cadillac parts

Genuine OEM, tested, and shipped ground from Jacksonville, Arkansas.

Cadillac parts and codes · Do not see it listed? Request a part or call 501-988-0611.
